Range of models
Whatever the job, large or small, light or heavy, we have the right tool in its breaker range

Operator friendly VR
The vibro-reduced handles with four dampening springs, central pivot pin and long solid steel handles give better vibration reduction and a high level of operator comfort

High power
Powerful, reliable performance day in and day out


We have the right tool for your need

BRK 40 - Lightweight, multi-purpose breakers
The perfect choice for indoor and outdoor renovation and demolition jobs, BRK 40 breakers have a good impact energy combined with a high frequency, at a comparable low-weight. Brickwork, frozen soil, asphalt, and concrete are no match for these tough, lightweight breakers. Frequently chosen by contractors and rentals, BRK 40 breakers are also effective for tamping and compaction and are used by railroad companies for tie tamping applications.

BRK 50 - Medium weight, multi-purpose breakers
A favorite with rental companies, BRK 55 breakers are the ideal choice for road building and maintenance applications. Whether it’s asphalt, brickwork, frozen soil, or concrete, the BRK 55 gives you reliable performance, especially when using a wide asphalt chisel on medium to hard asphalt. Can be used with both 30 l/min and 20 l/min power packs.

BRK 70 - Heavy-duty, multi-purpose breakers
Get the job done, fast! BRK 70 breakers are ideal for heavier jobs in tough materials such as asphalt, frozen soil, and reinforced concrete. They work at a standard flow rate of 30 l/min and at 20 l/min with a simple adjustment.

BRK 95 - Super heavy-duty breakers
Handheld breakers don’t get much more powerful than this. With probably the highest impact energy in its weight class and an impact rate of 1,275 blows/min., in some situations, the BRK 95 can even replace small excavators with breaker attachments. Ideal for breaking heavy asphalt, reinforced concrete and foundations, these powerful machines are the rugged choice for utility construction, street main-tenance, repair of water and gas lines and general construction jobs.

HBP = High Back Pressure
Models with the designation HBP are designed to accept the higher hydraulic return pressure that can be seen on most skid steers and when using extra long hose lengths. HBP breakers can be operated from the PTO outlet of most skid steers.

HYDRAULIC BREAKERS		BRK 40	BRK 40 VR	BRK 55	BRK 55 VR	BRK 55 HBP
Weight Without Hoses	kg	19.3	25.2	22.3	28.2	22.3
Length	mm	650	650	690	690	690
Oil Flow	l/min	20	20	20-30	20-30	20-30
Working Pressure	bar	95-110	95-110	105-125	105-125	115-130
Maximum Return Line Pressure	bar	10	10	15	15	35
Impact Rate	bpm	1,400	1,400	1,500-2,100	1,500-2,100	1,500-2,100
Vibration Level 3 Axes (ISO 28927-10)	m/s²	15.1	5	16.6	4.6	17.3 (20 lpm) 17.4 (30 lpm)
Sound Power Level Guaranteed (2000/14/EC)	Lw dB(A)	106	106	107	107	107
Sound Pressure Level (2000/14/EC)	(Lp, r=1m) dB(A)	93	93	95	95	95
EHTMA Class		C	C	C/D	C/D	C/D
Part Number	Chuck Size Hex 25 x 108mm	1801 3446 11	1801 3447 19	1801 3546 05	1801 3547 23	1801 3547 42
Part Number	Chuck Size Hex 28 x 152 mm	1801 3446 54	-	-	-	1801 3547 43
Part Number	Chuck Size Hex 28 x 160 mm	-	-	1801 3546 63	1801 3547 31	-
Part Number	Chuck Size Hex 32 x 152 mm	1801 3446 60	1801 3447 21	-	1801 3547 24	1801 3547 44
Part Number	Chuck Size Hex 32 x 160 mm	1801 3446 62	1801 3447 22	1801 3546 68	1801 3547 25	-

HYDRAULIC BREAKERS		BRK 70	BRK 70 VR	BRK 70 HBP	BRK 95	BRK 95 VR	BRK 95 HBP
Weight	kg	26.7	32.6	26.7	33.2	39.1	33.2
Length	mm	765	765	765	765	765	765
Oil Flow	l/min	20-30	20-30	20-30	30-40	30-40	30
Working Pressure	bar	110-125	110-125	115-130	110-125	110-125	115-130
Maximum Return Line Pressure	bar	15	15	35	15	15	20
Impact Rate	bpm	1,350-1,750	1,350-1,750	1,350-1,750	1,150-1,600	1,150-1,600	1,150-1,600
Vibration Level 3 Axes (ISO 28927-10)	m/s²	19.4	4.6 (20 lpm) 6.0 (30 lpm)	18.6 (20lpm) 18.1 (30 lpm)	20.1 (20 lpm) 19.7 (40 lpm)	5.4 (20 lpm) 6.3 (40 lpm)	20.1 (30 lpm) 19.7 (40 lpm)
Sound Power Level Guaranteed (2000/14/EC)	Lw dB(A)	107	107	107	106	106	106
Sound Pressure Level (2000/14/EC)	(Lp, r=1m) dB(A)	94	95	95	93	93	93
EHTMA Class		C/D	C/D	C/D	D/E	D/E	D
Part Number	Chuck Size Hex 25 x 108mm	-	-	1801 3647 45	-	-	-
Part Number	Chuck Size Hex 28 x 152 mm	-	-	-	-	-	1801 3746 85
Part Number	Chuck Size Hex 32 x 152 mm	1801 3646 70	1801 3647 27	1801 3647 37	-	-	1801 3746 76
Part Number	Chuck Size Hex 32 x 160 mm	1801 3646 07	1801 3647 28	-	1801 3746 09	1801 3747 30	-

VR = Vibro-reduced model HBP = High Back Pressure

Download Brochure: Handheld hydraulic equipment Construction equipment range guide
